AirQ

Energy efficient – VTOL fix wing

We are a UAS start-up in the Gulf Region focused on delivering the optimal Cargo solution to the region’s rapidly developing markets. Our latest work on ISTAR solutions allows us to present our modular aircraft solution: the “Harara.”

Both versatile and efficient, Harara is poised to operate in urban and remote environments, fulfilling multiple possible roles.

Modular design

The Harara UAV offers a wide array of utilities. We work closely with our customers to determine which configuration best suits their needs. The airframe’s powerplant, equipment, and VTOL capabilities will be customized prior to delivery.

Fully electric or ICE hybrid powerplants are available depending on performance needs. Concerning the mission purpose, thanks to our modularity, you can configure the airframe for CARGO or ISTAR roles.

Various sensor modules are available for reconnaissance missions. These sensors can be swapped in favour of an internal cargo bay. All these options are available in VTOL and STOL variants.

SENSOR
MODULE

CARGO
MODULE

Versatile and Efficient

Harara performs a more efficient take-off manoeuvre than traditional VTOL-capable fixed wing aircraft. During take-off, Harara aligns its airframe with the incoming airflow, increasing the aerodynamic lift during vertical take-off & throughout the transition to horizontal flight.

Thanks to the motor layout & proprietary software, Harara can take off and land anywhere for a fraction of the power cost.

Technical specifications

Units:
IMP SI
Drive:
ICE BEI
ItemSI – BEIIMP – BEISI – ICEIMP – ICE
Wingspan370 cm145 21/32 inches370 cm145 21/32 inches
MTOW32 kg70,4 lbs32 kg70,4 lbs
Payload6 kg13,2 lbs6 kg13,2 lbs
Cruise Speed100 km/h62,50 mph100 km/h62,50 mph
Ceiling2000 m6,262 ft3.500 m6,262 ft
Endurance2:30 hr:min2:30 hr:min6:00 hr:min6:00 hr:min

Highlights

1

1

The aircraft’s modular systems: Client Specific Solutions

An interchangeable bay for specific UAV purposes.

2

2

Our Improvements to In-Flight Performance

Intelligent tilting motors and folding rotors reduce drag in horizontal flight and increase maneuverability in multi-rotor mode.

3

3

The benefits of a nose-mounted gimbal sensor assembly.

A unique gimbal assembly position ensures maximum field of view and additional stability.

CONTROL CENTER

AirQ M-Ground Control System is an affordable, mobile and flexible GCS configuration.

A versatile design, offered in portable, mobile or stationary configurations, customized for the operators’ needs. The module offers ample workspace for two operators: the Remote Pilot plus the Payload Operator. It also provides secure transport for two UAVs. A reliable and quiet generator powers two Multifunctional Workstations, touchscreen displays and all communication equipment. HVAC and External lighting were incorporated to improve operational conditions at any time of day. With the illuminated surroundings, the assembly & operation of the UAV can be performed with both speed and precision.

CONTROL CENTER
